Home / Ovi-Scan sheep ultrasound scanner
Print / Share
Ovi-Scan sheep ultrasound scanner
Zoom photo Ovi-Scan sheep ultrasound scanner

Ovi-Scan sheep ultrasound scanner

Ref. Ovi6-Console

Ovi-Scan combines the Duo-Scan ultrasound scanner with a monitor console to give you a small and compact all-in-one ultrasound scanner.

Ref. Ovi6-Console
Contact us Demo Quotation

Overview

You will manage even in the worst of working conditions with this reliable and durable machine. The Ovi-Scan is dust proof, splash proof, and designed for on-farm use.

  • Compact sheep ultrasound with high quality screen
  • Unique 170° view allowing a larger and deeper view
  • Multiple frequency settings allowing visibility 28cm deep
  • Customizable ultrasound with several viewing, probe, and battery options
  • Determine the number of lambs

Technical Specifications

Sheep Ovine fertility and pregnancy
Deer Deer reproduction
Width (mm) 210
Depth (mm) 280
Height (mm) 240
Weight (kg) 5
Warranty 1 year

Accessories

Coming with the Ovi-Scan Kit is everything you need to maximise your scanning workflow. Our 3.5TT Axial probe has been trusted by sheep scanners for over 30 years. The Ovi-Scan can be removed from its display unit and used in ‘Duo-Scan’ mode in a backpack, using a BUG head-mounted viewing device allowing for flexibility of use.

We also provide a waterproof case, tally counter, RFID reader and gel feed bottle.

Related products

Duo-Scan Veterinary ultrasound scanner

Make your sheep or cattle ultrasound diagnosis quicker with 170° view More information

BUG:Go

Compatible with the innovative :Go family of ultrasound, the BUG:Go completes our wirel More information

Scanning Gel

Fills any tiny air pockets between the skin and the transducer that would impair the ab More information

Documents

Ovi Scan Leaflet

Ovi Scan Quick guide

Ovi Scan Manual

Care & Maintenance


We have built the Ovi-Scan to be rugged for the on-farm environment. It does contain sensitive electronics.  If you care for your Ovi-Scan properly you will get many years out of your product.

General

  1. Wipe it down after every use. Use a non-bleach antibacterial wipe or warm water and soap.
  2. Store in a dry environment.  Corrosion will occur if stored damp.
  3. Return your equipment annually to an IMV imaging service centre for a maintenance inspection.

Probe

  1. Clean the probe immediately after use before contaminates can dry on.  Immerse head in warm (not hot) water.  Do not store in cleaning/disinfecting solutions.
  2. Keep probe connector free of contaminates to maintain a good contact.
  3. Do not knock, scrape or push on the probe window. It could burst and cause damage.

Scanner

  1. Keeping all connectors clean and dry is especially important.  Examine them regularly for cracks or splits, if damage is found it is imperative to repair promptly.
  2. Wipe display gently with a lint free cloth. Cleaning cloth and cleaners for glasses/sunglasses work well. Care should be taken not to scratch the screen.
